| Floor LoadingWheel Load at Maximum Capacity | 126.7 psi | 873.6 kPa |
| Floor LoadingWheel Load at Minimum Capacity | 107 psi | 737.7 kPa |
| Floor LoadingWheel Load at 500 lbs Capacity | 122.2 psi | 842.5 kPa |
| SpecificationsGround Clearance Lowered | 3 in | 7.6 cm |
| SpecificationsGround Clearance Elevated | 0.3 in | 0.8 cm |
| SpecificationsPlatform Height Maximum (1 Person Indoor) | 18.4 ft | 5.6 m |
| SpecificationsPlatform Height Maximum (2 Person Indoor/1 Person Outdoor) | 11.6 ft | 3.5 m |
| SpecificationsPlatform Height Minimum | 31 in | 78.7 cm |
| SpecificationsWorking Height (1 Person Indoor) | 24.4 ft | 7.4 m |
| SpecificationsWorking Height (2 Person Indoor/1 Person Outdoor) | 17.6 ft | 5.4 m |
| SpecificationsOverall Length w/ Step | 69.5 in | 176.5 cm |
| SpecificationsOverall Width | 30 in | 76.2 cm |
| SpecificationsSlide Out Extension Deck Length | 30 in | 76.2 cm |
| SpecificationsPlatform Length | 57.8 in | 146.8 cm |
| SpecificationsPlatform Width | 21.8 in | 55.4 cm |
| SpecificationsStowed Height | 74.3 in | 188.7 cm |
| SpecificationsTires (Front/Rear) | 12/12 in | 30.5/30.5 cm |
| PerformanceDrive Speed Elevated (Proportional) | 0.6 mph | 0.3 m/s |
| PerformanceDrive Speed Lowered (Proportional) | 2.4 mph | 1.1 m/s |
| PerformanceSlide Out Extension Deck Capacity | 250 lbs | 113.4 kg |
| PerformanceGradeability | 30% | 30% |
| PerformanceInside Turn Radius | 8 in | 20.3 cm |
| PerformanceLift Speed (Up/Down) | 28/28 sec | 28/28 sec |
| PerformancePlatform Capacity | 650 lbs | 294.8 kg |
| PerformancePower Source | 24V DC | 24V DC |
| PerformanceRated Occupancy (Indoor/Outdoor) | 2/1 Person(s) | 2/1 Person(s) |
| Floor LoadingWeight | 1985 lbs | 900.4 kg |
