HB-P4.5

Push-Around Scissor Lift

The Hy-Brid Lifts HB-P4.5 scissor lift elevates workers, tools, and materials safely. As part of the Push-Around Series, this lift is compact and offers numerous features that make it the more productive alternative to ladders.

  • HB-P4.5
  • Hy-Brid Lifts by Custom Equipment

Key Features

  • Working height up to 4.5 m
  • Platform capacity up to 250 kg
  • Low floor load pressures
  • Full swing entry gate
  • 12V AGM battery
  • Non-marking wheels
  • 2-year parts warranty
  • 5-year structural warranty
  • CE certified

Options

  • Power-to-platform
Maximum Wheel Load338 psi2230 kPa
Minimum Wheel Load205 psi1415 kPa
Ground Clearance1.57 in0.04 m
Platform Height Max (indoors)8 ft2.5 m
Platform Height Min25.25 in0.6 m
Working Height (indoors)14.76 ft4.50 m
Overall Length43 in1.09 m
Overall Width27.55 in0.70 m
Platform Length37 in0.94 m
Platform Width22 in0.56 m
Stowed Height68.56 in1.74 m
Lift Speed Up/Down16/16 sec16/16 sec
Platform Capacity550 lbs250 kg
Rated Occupancy1 Person1 Person
Weight773 lbs351 kg
